Solid aluminium alloy chassis, brushed panel.
Quad-core ARM Cortex-A55 professional processor.
6" large LCD colour touchscreen, easy control.
Based on Android 11, deeply tailored system.
4GDDR+32GeMMC large memory for masses of applications.
Support M.2 NVME 3.0 SSD (not included), up to 4TB.
2xES9038Q2M DAC for independent stereo decoding.
Support DSD512 Native, PCM768KHz@32Bit, MQA full decoding.
The 3rd generation XU316 for higher performance and processing speed.
Dual femtosecond clocks, ultra-low phase noise, ultra-low jitter clock synchronization processing, purer output.
Fully balanced circuit, XLR balanced and RCA single-ended hi-fi pre-out.
2x DOH chips, support HDMI DSD Native and D2P multi-channel output(Up to 5.1).
Qualcomm QCC5125 Bluetooth 5.0 module with APTX HD.
Low noise, high quality power supply, providing pure power source for audio circuits.
Support mastering audio formats DSD (.dsf/.dff/.iso/.dst), APE, FLAC, WAV, MQA, etc.
Support 2-channel and Multi-channel Gapless playback(FLAC,WAV)
Personalised music management, and music data matching.
EOS audio engine developed by Eversolo, globally bypassing SRC restrictions.
Support Direct audio in 3rd party APPs (Apple Music hi-res direct output).
Full decoding and rendering support for MQA on Optical, Coaxial and USB input etc.
Support USB, Optical, Coaxial, HDMI digital audio Bit-perfect output.
Support external USB optical drive for CD disc playback and CD ripping.
Music services Tidal, Qobuz, Highresaudio, Amazon etc.
Support Roon ready, Tidal Connect, etc.
Support music playback from DLNA.
Support NFS, SMB, Web DAV, UPnP protocols to access storage devices shared in the LAN.
Support built-in SMB network media sharing service for easy local media sharing.
Exclusive mobile APP for Android/IOS mobile phones and tablets.
Specs
EVERSOLO DMP-A6
Display
6" LCD touchscreen
Internal Memory
4GDDR4 +32GeMMC
DAC
ES 9038Q2M*2
Audio Processor
XMOS XU316
Op-amp Chip
OPA1612
Power Supply
Low noise, high quality switching power supplies
SSD
M.2 NVME 3.0 2280 protocol, up to 4TB
USB-A Port
USB3.0*2
Ethernet
RJ-45(10/100/1000Mbps)
WiFi
WiFi 2.4G+5G dual band
Playback and DAC Decoding
Support up to stereo DSD512, PCM 768KHz 32Bit, MQA
Music Service
Tidal, Qobuz, Highresaudio, Deezer, Paradise Radio,WebDAV, UPnP
Streaming
Air Play, DLNA, Tidal Connect, Qobuz Connect etc.
Bluetooth Audio Input
BLuetooth BT5.0, support SBC/AAC/aptX/aptX LL/aptX HD/LDAC
USB-C Audio Input
USB-C Audio Input：Supports Windows (10, 11), Android, IOS.
Support up to stereo DSD512, PCM 768KHz 32Bit, MQA
Optical/Coaxial Audio Input
Support up to stereo PCM 192KHz 24Bit, DSD64 Dop, MQA
Optical/Coaxial Audio Output
Support up to stereo PCM 192KHz 24Bit, DSD64 Dop, MQA
HDMI Audio Output
DSD64 Native multi-channel/PCM192KHz multichannel raw output(Up to 5.1)
Control Method
Mobile App，Touch screen control
XLR Output Audio Characteristics
Output level: 5.2V
Frequency response: 20Hz~20KHz(±0. 15dB)
Dynamic range: > 128dB
SNR: >128dB
THD+N: <0.00009%(-120dB) @A-wt
Crosstalk: >-125dB
RCA Output Audio Characteristics
Output level: 2.6V
Frequency response: 20Hz~20KHz (±0. 2dB)
Dynamic range: > 124dB
SNR: >124dB
THD+N: <0.00011%(-119dB)@A-WT
Crosstalk: >-124dB
PSU
AC 110~240V 50/60Hz
Rated Power
13W
Dimensions
L 187mm* W 270mm* H 90mm
Packing List
Power cable*1, USB cable*1，Screwdriver*1，user manual*1
